CrossLink-NX

Built on the Lattice Nexus platform, Lattice CrossLink-NX FPGA, featuring 10 Gbps MIPI D-PHY bandwidth, provides best-in-class power and performance for Embedded Vision and Edge AI applications.

Built on the Lattice Nexus Platform - Up to 75% lower power vs similar FPGAs and small form factor packaging with sizes as small as 4 mm x 4 mm.

Provides Best-in-class Performance for Vision Processing Applications - High memory to logic cell ratio, up to 170 bits per logic cell, accelerates AI inferencing.

High Speed Interfaces - 2.5 Gbps Hardened MIPI D-PHY, 5 Gbps PCIe, 1.5 Gbps programmable I/O, 1066 Mbps DDR3. Supporting LVDS, subLVDS, OpenLDI (OLDI), and SGMII.

Features

Instant-on configuration – IO configures in 3 ms, and device as fast as 8 ms

Two hardened 4-lane MIPI D-PHY transceivers at 10 Gbps per PHY / 2.5 Gbps per lane

Up to 37 programmable source synchronous I/O pairs for camera and display interfacing

From 4 mm x 4 mm WLCS package (0.4 mm pitch) to 17 mm x 17 mm BGA package (0.8 mm pitch)

Lowest soft error rate in its class, 100X more reliable than competition

Available in Commercial, Industrial and Automotive (AEC-Q100 qualified) temperature grades
